Planet L2+/L4 48-Port 10/100/1000T 802.3at PoE...
Planet L2+/L4 48-Port 10/100/1000T 802.3at PoE + 4-Port 10G

Planet L2+/L4 48-Port 10/100/1000T 802.3at PoE + 4-Port 10G

Planet
DS1_GS-5220-48P4X
Immediatamente Disponibile
1.296,44 €
Tasse incluse

  • Data di consegna prevista:
  • UPS EXPRESS
    UPS EXPRESS - Acquista entro e ricevilo Giovedì 24 Aprile, 2025
  • Corriere Standard
    Corriere Standard - Acquista entro e ricevilo Venerdì 2 Maggio, 2025


  • Physical Port
  • 48 10/100/1000BASE-T Gigabit RJ45 copper ports with 48-port IEEE 802.3af/at PoE+ injector function
  • 4 10GBASE-SR/LR SFP+ slots, compatible with 1000/2500BASE-SX/LX/BX SFP
  • RJ45 console interface for switch basic management and setup
  • Power over Ethernet
  • Complies with IEEE 802.3at Power over Ethernet Plus/end-span PSE
  • Backward compatible with IEEE 802.3af Power over Ethernet
  • Up to 48 ports of IEEE 802.3af/IEEE 802.3at devices powered
  • Supports PoE power up to 36 watts for each PoE port
  • Auto detects powered device (PD)

Specifiche del prodotto

Data transmission
Jumbo frames10000
Jumbo frames supportYes
MAC address table16000 voci
Packet buffer memory32 MB
Store-and-forwardYes
Switching capacity176 Gbit/s
Throughput130 Mpps
Design
CertificationFCC Part 15 Class A, CE
Form factor1U
LED indicatorsYes
Number of fans3 ventola(e)
Product colourBlue
Rack mountingYes
Reset buttonYes
Legal Information
UNSPSC Code43222612
Management features
ARP inspectionYes
Quality of Service (QoS) supportYes
Switch layerL3
Switch typeManaged
System event logYes
Traffic classificationYes
Web-based managementYes
Multicast features
Multicast supportYes
Network
Auto MDI/MDI-XYes
Auto-negotiationYes
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Flow control supportYes
Full duplexYes
Link aggregationYes
MAC address auto-aging supportedYes
MAC address auto-learning supportedYes
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs4095
Port mirroringYes
Spanning tree protocolYes
Virtual LAN featuresPrivate VLAN, Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN
VLAN supportYes
Operational conditions
Heat dissipation1582 BTU/h
Operating relative humidity (H-H)5 - 95 %
Operating temperature (T-T)0 - 50 °C
Storage relative humidity (H-H)5 - 95 %
Storage temperature (T-T)-10 - 70 °C
Package dimensions
Depth (package,cm)59 cm
Gross Weight (Package, kg)6,32 kg
Height (package,cm)42 cm
Width (package,cm)21 cm
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Console portRJ-45
Gigabit Ethernet (copper) ports quantity48
SFP+ module slots quantity4
Power
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Input current7 A
Power consumption (max)461 Watt
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity48
Power over Ethernet (PoE) power per port36 Watt
Total Power over Ethernet (PoE) budget400 Watt
Product dimensions
Net Weight (Product, kg)4,94 kg
Product Depth30 cm
Product Height4,45 cm
Product Width44 cm
Security
Access Control List (ACL)Yes
Access Control List (ACL) rules256
DHCP featuresDHCP snooping, DHCP relay
IGMP snoopingYes
Security algorithmsSNMPv3, SSH, SSL/TLS
SSH/SSL supportYes
Vendor information
Brand NamePlanet
Warranty3 Anno(i)
