Managed Ethernet switch with 3x 10/100BaseT(X) ports, 2x 100BaseFX multi-mode ports ST, 0 - 60°C
The EDS-505A/508A are standalone 16-port managed Ethernet switches. With their advanced Turbo Ring and Turbo Chain technology (recovery time < 20 ms) and RSTP/STP (IEEE 802.1w/D), the EDS-505A/508A switches increase the reliability and availability of your industrial Ethernet network. Models with an wide operating temperature range of -40 to 75°C are also available, and the switches support several reliable and intelligent functions, including IEEE 1588 PTP, Modbus/TCP, LLDP, SNMP Inform, QoS, IGMP snooping, VLAN, IEEE 802.1X, HTTPS, SNMPv3, and SSH, making the EDS-505A/508A switches suitable for any harsh industrial environment.- IPv6 Ready logo awarded (IPv6 Logo Committee certified)- IEEE 1588 PTP (Precision Time Protocol) for precise time synchronization of networks - DHCP Option 82 for IP address assignment with different policies - Modbus/TCP industrial Ethernet protocol supported - Turbo Ring and Turbo Chain (recovery time < 20 ms at full load), and RSTP/STP (IEEE 802.1w/D)- IGMP snooping and GMRP for filtering multicast traffic- Port-based VLAN, IEEE 802.1Q VLAN and GVRP to ease network planning- QoS (IEEE 802.1p/1Q) and TOS/DiffServ to increase determinism- Port Trunking for optimum bandwidth utilization- RMON for efficient network monitoring and proactive capability- SNMPv1/v2c/v3 for different levels of network management- IEEE 802.1X, HTTPS, and SSH to enhance network security - Bandwidth management prevents unpredictable network status- Lock port function for blocking unauthorized access based on MAC address- Port mirroring for online debugging- Automatic warning by exception through e-mail and relay output
- Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), and STP/RSTP/MSTP for network redundancy
- TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance network security
- Easy network management by web browser, CLI, Telnet/serial console, Windows utility, and ABC-01
- Supports MXstudio for easy, visualized industrial network management
Specifiche del prodotto
| Data transmission | |
| Maximum data transfer rate | 0,1 Gbit/s |
| Packet buffer memory | 1 MB |
| Supported data transfer rates | 10/100 Mbps |
| Design | |
| Certification | FCC Part 15, CISPR, DNV, GL |
| Safety | UL508, UL60950-1, CSA C22.2 No. 60950-1, EN60950-1 |
| Management features | |
| MIB support | MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9 |
| Switch type | Managed |
| Network | |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Flow control support | Yes |
| Full duplex | Yes |
| IP address table | 4094 |
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Number of VLANs | 64 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Relative humidity | 5 - 95 % |
| Storage temperature (T-T) | -40 - 85 °C |
| Optical fiber | |
| Fiber ethernet cabling technology | 100BASE-FX |
| Fiber type | Multi-mode |
| Link budget | 12 dB |
| RX sensitivity | -32 dB |
| Wavelength | 1300 nm |
| Other features | |
| Connectivity LEDs | 1 |
| Connectivity technology | Wired |
| Dimensions (WxDxH) | 80.2 x 135 x 105 mm |
| Electromagnetic emissions | EN61000-4-2 (ESD), EDS-505A: lvl 3; EDS-516A: lvl 2; EN61000-4-3 (RS), lvl 3; EN61000-4-4 (EFT); EN61000-4-5 (Surge); EN61000-4-6 (CS); EN61000-4-8 |
| Mounting | Y |
| Mounting interface | DIN-Rail |
| Networking features | Ethernet, Fast Ethernet |
| Shock | IEC 60068-2-27 |
| Package dimensions | |
| Depth (package,cm) | 17 cm |
| Gross Weight (Package, kg) | 1,7 kg |
| Height (package,cm) | 10 cm |
| Width (package,cm) | 23 cm |
| Performance | |
| Mean time between failures (MTBF) | 352000 Hour |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 3 |
| Fiber optic connector | ST |
| Fiber ports quantity | 2 |
| Power | |
| Input current | 0.35 A |
| Input voltage | 24 V |
| Power source | VDC |
| Redundant power supply (RPS) support | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Product dimensions | |
| Net Weight (Product, kg) | 1,5999999999999999 kg |
| Protocols | |
| Supported network protocols | GMPv1/v2 device, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, BootP, TFTP, SNTP, SMTP, RARP, GMRP, LACP, RMON, HTTP, HTTPS, Telnet, Syslog, DHCP Option 66/67/82, SSH, SNMP Inform, Modbus/TCP, LLDP, IEEE 1588 PTP, IPv6 |
| Security | |
| IGMP snooping | Yes |
| Vendor information | |
| Brand Name | Moxa |
| Warranty | 2 Anno(i) |
