8-port entry-level managed Ethernet switches
EDS-408A/405A series switches are entry-level 8- and 5-port managed Ethernet switches that are designed especially for industrial applications. The switches support many different managementfunctions, such as Turbo Ring, ring coupling, VLAN, QoS, RMON, bandwidth management, port mirroring, and warning by email or relay. The ready-to-use Turbo Ring can be set up easily using a web-based management interface, or simply by using the default settings, which are plug-and-play.Industrial Networking Capability-Plug-n-Play, Turbo Ring (recovery time < 20 ms at full load) and RSTP/STP (IEEE802.1 W/D) capability-Port-based VLAN to ease network planning-QoS-IEEE 802.1p/1Q and TOS/DiffServ to increase determinism-RMON for efficient network monitoring and proactive capability-SNMP V1/V2c/V3 for different levels of network management securityDesigned for Industrial Applications-Bandwidth management prevents unpredictable network status-ABC-01 (Automatic Backup Configurator) for system configuration backup-Port mirroring for online debugging-Automatic recovery of connected device's IP addresses-Line-swap fast recovery (Patented)-Redundant, dual DC power inputs-Regular (0 to 60°C) and extended (-40 to 75°C) operating temperature models available-IP30, rugged high-strength case-Long-haul transmit distance of 40 km-DIN-Rail or panel mounting capability-Configurable by Web browser, Telnet/Serial console, Windows utility-Ping commands to identify network segment integrityRecommended Software and Accessories- ABC-01 RS-232 RJ45-based Automatic Backup Configurator- EDS-SNMP OPC Server Pro- DR series DIN-Rail 24 VDC power supplies
- Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), and RSTP/STP for network redundancy
- IGMP Snooping, QoS, IEEE 802.1Q VLAN, and port-based VLAN supported
- Easy network management by web browser, CLI, Telnet/serial console, Windows utility, and ABC-01
- PROFINET or EtherNet/IP enabled by default (PN or EIP models)
- Supports MXstudio for easy, visualized industrial network management
Specifiche del prodotto
| Design | |
| Safety | UL508, UL60950-1, CSA C22.2 No. 60950-1, EN60950-1 |
| Management features | |
| MIB support | MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON 1, 2, 3, 9 |
| Switch type | Managed |
| Network | |
| Flow control support | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Relative humidity | 5 - 95 % |
| Storage temperature (T-T) | -40 - 85 °C |
| Other features | |
| Connectivity LEDs | PWR1, PWR2, FAULT, MASTER, COUPLER, 10/100M |
| Dimensions (WxDxH) | 53.6 x 105 x 135 mm |
| Mounting interface | DIN, Wall |
| Power requirements | 24 VDC (12 - 45 VDC) |
| Package dimensions (verified) | |
| Depth Verified | 17 cm |
| Gross Weight Verified | 1,072 kg |
| Height Verified | 9,8 cm |
| Width Verified | 20,1 cm |
| Performance | |
| Mean time between failures (MTBF) | 363000 Hour |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Product dimensions | |
| Net Weight (Product, kg) | 0,9720000000000001 kg |
| Protocols | |
| Supported network protocols | GVRP, SNMP V1/V2c/V3, DHCP Server/Client, DHCP Option 82, BootP, TFTP, SNTP, SMTP, RARP, LACP, RMON |
| Security | |
| DHCP features | DHCP server, DHCP client |
| Vendor information | |
| Brand Name | Moxa |
| Warranty | 2 Anno(i) |
